Download a PDF format catalog on magnifiers
Magnifiers and hand-held microscopes are used by printers,
silkscreeners, PCB manufacturers, quality control workers, collectors of coins, stamps
& antiques, naturalists, needleworkers, forensics specialists, hobbyists,
conservators, geologists and others.
Low vision aids and vision enhancers, including reading lenses, Bausch
& Lomb visors, hands-free and illuminated pocket magnifiers are ideal for everyday
tasks and hobbies as well as for those suffering from macular degeneration.
If you don't see the magnifier you want, please call, fax or e-mail and let
us try to locate it!
Keep in mind that for all magnifiers, there is a general relationship between the
three key specifications for a lens: the diameter, the focal length (working
distance between the surface and the lens), and the power. Generally, a higher power
magnifier will have a smaller diameter and shorter focal or working distance than a lower
power magnifier. That's why, for example, it is not optically possible to make a 1 x 1
linen tester in 10X or why the 20X inspection loupe has a smaller lens than the 12X and
less room to work underneath.
Click to go to
our on-line order page
 WF-6:
This brand-new magnifier offers an unbeatable combination of distortion-free
6 power magnification and lots of room to work underneath! The viewing
area is 2 inches across and 1-1/2 inches tall! The double ashperic design guarantees excellent clarity and sharpness from edge-to edge of
the 33mm diameter lens, while the cutaway base allows 180º
access to the subject. The focus is fully adjustable. A plastic cap is included to protect the
lens. You'll find this magnifier available elsewhere for over $79, but
our price is just $42!!
 LM-10:
This handy, inexpensive magnifier is equipped with a powerful,
flat-field 10X lens (25mm diameter) and built-in illumination from two
bright-white LED lamps. You'll have no trouble seeing fine detail on
prints, stamps, coins, and photos. You can even use it to detect
counterfeit currency and secure documents, because you can easily see the
micro-printed area.
The ergonomically-shaped body fits comfortably into
your hand and allows your thumb to operate the push-button switch that turns
on the light. Uses two AAA batteries, included. Long battery
life is assured by LED technology, compared to incandescent bulbs.
Only $46!!
For general purpose magnification. All fold up flat for easy carrying.
 |
 |
 |
 |
MLT-6 / MLT-9
BLT-4 |
CLT-10 |
PLT-8 |
MLT-10 |
- MLT-6: The most popular magnifier we sell, 6 power, double element glass lens,
anodized metal frame with etched measuring scale around the 1"x1"
opening, 1½" working height, vinyl pouch, $17.
- MLT-9: As above, but 9 power, ½"x½" opening, 1" working height,
$20.
- MLT-10: As above, but 10 power, with a single,
rather than double lens, $22.
- CLT-10: A 10X chrome linen tester ½"x½" opening,
snaps open with a spring, just like the old brass linen testers which are no longer
available. Comes in vinyl case for safe storage, $20.
- BLT-4: GIANT-SIZED! Glass lens, plastic frame, 4"x4"
opening, 6" working height, great for everything from reading maps to looking at
photographs, $22.
- PLT-8: 8 power, plastic lens and frame,
¾"x¾" opening,
1½" working height, imprinting available $11.
(See detailed specifications)
Used where higher quality optics are needed. All have
color-corrected, multi-element glass lenses for "flat-field" (distortion-free)
viewing across the entire working area. Threaded lens mounts allow adjustable
focus with locking rings to retain focus. "W" series have jumbo 19
mm lenses for a 60% larger viewing area.
 |
 |
 |
FM-10
FM-12W / FM-20 |
PH-12W |
SW-12W |
- FM-10: 10 power, folds up to protect lens when carrying, $55.
- FM-12W: As above, but extra wide (19mm)
lens, $64.
- FM-20: As above, but 20 power, $72.
- PH-12W: 12 power, extra wide (19 mm) lens, acrylic base makes an
ideal stripper's loupe, or for use on a light table, $64.
- SW-12W: As above, extra wide lens, but with swivel base, $64.
(See detailed specifications)
Caprock LensMaster System:
CV-10 Color Viewer / LS-10 Surface Checker |
The Caprock LensMaster system includes a 10 power distortion-free Bausch &
Lomb Hastings triplet lens plus two light sources to help you examine surface features and
irregularities by casting "shadows" on any surface. Great for checking
paper, fabric, gemstones, plastics, insects, antiques, paintings, etc. Two AA
batteries included. Light weight (4 ounces) plus the
hard-shell molded case make it easy to take these with you wherever you go!
- CV-10: Ideal for printers, silkscreeners, and anyone who needs to view hard-to-see
yellow printing and colors from the press of in color proofs. A terrific tool to
calibrate output of digital printers. Utilizes a high transmission blue filter that
slips over the lens to enhance viewing of yellow, less than one-third the cost of
competitive viewers, $110.
Additional filters in red or green, $40.
- LS-10: Far superior than doublet and triplet "jeweler's loupes"
for those who need to examine surface features of flat and 3D objects, ranging from
insects to gems to stamps & coins to silkscreen mesh. The two light sources cast
shadows to highlight and illuminate irregular surfaces, $85.
- Optional reticles (scales), by Bausch and Lomb, allow precise
measurement in inches, millimeters, angles, or a combination of all three, $40 each.
| Special Purpose/Low Vision Magnifiers |
Doublets for jewelers, coin & stamp collectors, "Egg Cup" for
large viewing area, rectangular Reading Glass for the "fine print" and an 8
power measuring magnifier.
 |
 |
 |
 |
 |
|
| SO-14/21 |
EC-8 |
WT-6 |
MM-10 |
TSF-8 |
|
- SO-14: 10 power jeweler's loupe, 14 mm diameter doublet
lens, small size folds up so it's easy to carry with you, chrome-plated, $15.
- SO-21: As above, but 21 mm diameter triplet lens,
$20.
- EC-8:
8 power very economical plastic magnifier is great for
looking at slides, stamps, coins, photographs, printed sheets, etc.
Multiple-element lens, 1-1/2 inches tall, 25 mm diameter lens, $16.
- WT-6: A giant version of the EC-10 above, this magnifier has a 6
power lens with a 50 mm diameter lens gives a much larger viewing area than the EC-10,
heavy acrylic base, $20.
- MM-10: 10 power Hastings triplet magnifier with your choice of a
Bausch & Lomb measuring reticle in inches, metric, angle (protractor) or a combination
of the three, with leather carrying case, $99.
- TSF-8: 8 power measuring magnifier has a built-in scale to
measure points (1 point divisions) for type size and inches
(0.01" divisions) to measure length and count threads, $25.
- TSF-8 (mm): As above, but with scales in points and millimeters
(divisions of .5 mm),
$25.
NOTE: Call for details on round reading glasses and free-standing gooseneck
magnifiers not described above.
For quick alignment of register marks, film and other surfaces. Eliminate
"parallax" errors by forcing the eye to look straight down.
StripMaster Para-Mag
- SM-7: StripMaster™, threaded focus with locking ring to retain focus, $68.
- SM-10: As above, but 10 power lens, $79.
- SM-12: As above, but 12 power lens, $84.
- PM-7: Tobias Para-Mag, 7 power lens, friction focus, $68.
- PM-10: As above, but 10 power lens-
discontinued use SM-10 above.
(See detailed specifications)
Click for details on our selection of portable and pocket-sized microscopes in a
range from 30 to 300X. including illuminated and measuring models.
TOP OF PAGE
Call, fax or e-mail
for free catalog with more details, and other styles available!
